General Electric's IS200LSGIH1A interfaces between the UCSB controller and the power conversion bridges, the analog outputs (0 to 10 V), and more.

.Many products are not yet on the shelves please contact us for more products

.If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation

.We have 20 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

Product Description

Providing bridge instantaneous overcurrent protection independent of the controller, the General Electric IS200LSGIH1A is a Static Starter Control Gating Interface. The board functions as an interface between the UCSB (Universal Version B Standalone Controller) controller and the power conversion bridges, analog outputs, contact input of pretrigger, and the analog input cooling returns. In the case that an instantaneous overcurrent transpires, the LSGI can open the 52SS and remove input power from the bridges, shielding the unit from damage. The LSGI works with the three FGPA boards to control the six thyristors on each bridge.

The main power supply furnishes the LSGI with 28 V DC; the LSGI can then distribute it through the control cabinet. The current powers not only the LSGI board, but the UCSB controller, LSTB board, and the 8-port switch as well. General Electric's IS200LSGIH1A also passes ±24 VDC from the main power supply to the FCSA, which then powers the LEMs. The FCSA board sends its signals to the LSGI via a copper wire which is attached to a 12-pin plug housed on the LSGI. The LSGI also receives data from the FGPA (Trigger Pulse Amplifier), which collects SCR voltage information from the FHVA (High Voltage Gate Interface) card.
