What are the functions of ABB RED670

ABB RED670 is an intelligent electronic device (IED) with numerous powerful features. It has phase isolation current differential protection function, excellent sensitivity to high resistance faults, and provides safe phase selection for up to 5 line terminals. Two winding or three winding power transformers can be included in the protection zone. The device also has scalable hardware and rich configuration opportunities, which can meet the specific requirements of different users.

In terms of protection functions, RED670 provides comprehensive protection, including overcurrent, overload, short circuit, ground fault, etc., to ensure the safe operation of power equipment and systems. It also has automatic or manual synchronization check function and automatic reclosing function, suitable for single or multiple circuit breaker arrangements, covering single-phase and three-phase tripping situations. In addition, it can also be configured with optional software functions such as distance protection, control, and monitoring.

RED670 has multiple communication interfaces, supports multiple communication protocols, and can be integrated with other smart devices and systems to achieve remote monitoring and control. It can record event and fault information, helping operation and maintenance personnel analyze system operation status and the causes of faults. At the same time, the device is equipped with an intuitive graphical user interface, making operation and monitoring more convenient, and has an adaptive parameter setting function that can intelligently adjust according to the system's operating status and changes.

Application of ABB RED670 in Power Protection

ABB RED670 has a wide range of applications in power protection. It is mainly used for protecting, monitoring, and controlling overhead lines and cables, and can handle transformer feeders, generators, and transformer blocks. In terms of overhead line protection, it is suitable for the protection of heavy-duty lines and multi terminal lines, with tripping requirements of single pole, double pole, and/or triple pole. For cable protection, it also performs well, being able to quickly and accurately detect faults and provide effective protection.

In the power system, RED670 can be applied for power plant protection, used to protect generators, transformers, and related equipment in power plants; Power grid protection, used for the protection of lines and equipment in the power grid, ensuring the stability and safety of the power grid; In industrial power systems, protecting factory equipment, motors, and power distribution systems; And in the field of renewable energy, such as wind and solar power generation systems, protecting inverters and devices connected to the power grid. In addition, it can also be used in railway electrification systems to ensure the safe and reliable operation of the electrification system.

Configuration flexibility of ABB RED670

The ABB RED670 has extremely high configuration flexibility. It has four different software options available for ordering, which are suitable for most applications with only minor or no changes needed. On the PCM600 engineering platform, minor modifications can be made to binary inputs and outputs using the signal matrix tool. The main protection function is turned off upon delivery, and backup functions that are not usually used can also be set to Off.

This device can be used in applications with single bus or double bus single circuit breakers, and the protection scheme includes three-phase tripping and three-phase automatic reclosing scheme with synchronous inspection. Differential protection can protect up to 3 CT units, with 2-3 line ends as the main protection function. It has a communication module with single or redundant channels, which can be used for arranging two or more terminals. Optional distance protection can be provided, and the measurement functions of S, P, Q, I, U, PF, f can be used for local HMI and/or remote representation.

Email:  plc66@qq.com

Phone: +86 18059884790(WHATSAPP/WeChat)

Sales:LIMING

The price is subject to confirmation by the contact person LI MING (manager).

Product: Brand new original packaging

Payment method: 100% telegraphic transfer. Conditions can be negotiated before shipment of inventory goods!

If you have any downtime spare parts that cannot be found, please feel free to call or contact me via email at any time.

If there are any issues that the product cannot solve, please contact me.

Many products have not been listed yet. Please contact us for more products！！！

If there is any inconsistency between the product model and the displayed picture, the model shall prevail.

Please contact us for specific product pictures, and we will arrange for photos to be taken in the warehouse for confirmation

We have 22 shared warehouses worldwide, so please understand that sometimes it may take several hours to respond accurately to you.

Of course, we will respond to your concerns as soon as possible

 Our company can directly purchase from overseas, can provide different countries, manufacturers of equipment and spare parts, to solve your many places to find trouble or worry about product quality problems, etc., in the price we have a great advantage, product details, we sincerely welcome you to inquire or use E-mail query!

The company to stop production control system parts, as the advantage of productsAs long as you want, I can help you find! The price is excellent!
