"YOKOGAWA PSCDM024DCBAN-A5E0024837106" is a product of Yokogawa Corporation. The relevant information is as follows:

• Product type: Is an input/output (I/O) board or module.

• Function: In the automatic control system, it is used to realize the input and output of the signal, connect the field equipment and the control system, and carry out data acquisition and control signal transmission. For example, the signal of the sensor (such as temperature, pressure, flow, etc.) can be collected, and the control signal is sent to the actuator (such as valves, motors, etc.) to achieve the monitoring and control of industrial processes.

• Technical specifications:

• Power supply requirements: On-site power supply 24VDC±10%, the maximum current up to 8.0A; With overvoltage protection, the detection level is 32V or lower; The voltage between the output and the ground is 500VAC or higher for 1 minute; The capacitance between the output and the ground is 0.4μF or less (the total capacitance needs to meet this condition when multiple parallel power supplies are used).

• Mounting method: Supports DIN rail mounting type (A2BN3D-0) or wall mounting with 4 M4 screws (A2BN3D-1).

• Number of installed components: Two I/O modules can be installed. Can connect up to 16 I/O adapters.

• Number of channels: Has 16 channels.

• Connection mode: The system power supply is connected through the baseboard power supply cable (A2KPB00); Connect the onsite power supply to the onsite power supply terminal using a cable (0.5 to 1.5mm² in size). M3 screw terminals are provided for grounding. For on-site signal connection, separate cables (0.5 to 2.5mm²) are required for the pressure clamp terminal (a2BN3d- 1) and spring clamp terminal (a2BN3d- 2), or cable connectors (a2BN3d- 9) can be used. Connect to the F-SB bus via the F-SB bus cable (A2KLF00).

• Other features: There are certain requirements for voltage resistance and insulation resistance between the site and the system and between channels (withstand voltage 1500VAC between the site and the system for 1 minute, insulation resistance 100MΩ or higher; Withstand voltage 500VAC between channels, lasting 1 minute, insulation resistance 100MΩ or higher); Install a false cover (A2DCV01) if the I/O module has unused slots. Install a passthrough I/O signal adapter (A2SMX801) if the I/O adapter has unused slots.

Email:  plc66@qq.com

Phone: +86 18059884790(WHATSAPP/WeChat)

Sales:LIMING

The price is subject to confirmation by the contact person LI MING (manager).

Product: Brand new original packaging

Payment method: 100% telegraphic transfer. Conditions can be negotiated before shipment of inventory goods!

If you have any downtime spare parts that cannot be found, please feel free to call or contact me via email at any time.

If there are any issues that the product cannot solve, please contact me.

Many products have not been listed yet. Please contact us for more products！！！

If there is any inconsistency between the product model and the displayed picture, the model shall prevail.

Please contact us for specific product pictures, and we will arrange for photos to be taken in the warehouse for confirmation

We have 22 shared warehouses worldwide, so please understand that sometimes it may take several hours to respond accurately to you.

Of course, we will respond to your concerns as soon as possible

    Our company can directly purchase from overseas, can provide different countries, manufacturers of equipment and spare parts, to

solve your many places to find trouble or worry about product quality problems, etc., in the price we have a great advantage, product

details, we sincerely welcome you to inquire or use E-mail query!

The company to stop production control system parts, as the advantage of products

As long as you want, I can help you find! The price is excellent!

Main products, superior supply, adequate inventory
