The ABB CT-ERS.12S is a single-function electronic time relay from ABB. The following are some of its main features and technical parameters:

Function: Provides the on-delay (delay on) function, that is, the circuit is switched on after a delay of a period of time.

Time range: There are 10 time ranges, from 0.05 seconds to 300 hours.

Control power supply voltage: The rated control power supply voltage is 24-48V DC / 24-240V AC.

Output: 1 C/O (single pole double throw) contact with an output contact rating of 250V / 4A.

Protection level: The protection level of the shell is IP50, and the protection level of the terminal is IP20.

Size and weight: Net width 22.5mm, net height 85.6mm, net depth/length 103.7mm, net weight 0.106kg.

Other features: With a sealable transparent cover to protect against unauthorized changes; Using screw connection technology, with double cavity cage connection terminal.

Some of its technical parameters are as follows:

Rated operating voltage: auxiliary circuit 250V; Frequency 50/60Hz DC.

Rated operating current: AC-12 (230V) 4A, AC-15 (230V) 3A; Dc-12 (at 24V) is 4A, DC-13 (at 24V) is 2A.

Minimum switching capacity: 100mA at 12V.

Rated pulse withstand voltage: input circuit 4kV, output circuit 1 / output circuit 2 4kV.

Rated insulation voltage: input circuit/output circuit 500V, output circuit 1 / output circuit 2 300V.

Electrical durability: AC -12 for 100,000 cycles.

Mechanical durability: 300 million cycles.

Connection capability: Flexible wire with collar 1x 0.5-2.5 mm², flexible wire with collar 2x 0.5-1.5 mm², flexible wire with insulation collar 1x 0.5-2.5 mm², flexible wire with insulation collar 2x 0.5-1.5 mm², flexible wire 1x 0.5-2.5 mm², Soft cable 2x 0.5-1.5 mm², hard cable 1x 0.5-4 mm², hard cable 2x 0.5-2.5 mm².
