Product Description

The GE Inverter Snubber Board DS200ITXSG1ABB features one 8-pin connector, two 2-pin connectors, and multiple test points. It also is populated with four capacitors. The test points are a useful tool for servicers because they enable the various circuits on the board to be tested. The testing device must be approved for the purpose and properly calibrated. The probes must be designed for use with the tester. Inspect the probes and make sure any insulation on the probes is in good condition and is not worn. When the board is tested, first wear a wrist strap and use a screwdriver to remove the screws that attach the board to the rack. Note where cables are connected and tag the cables with information so that you can re plug the cables when you reinstall the board. When you remove the board, keep it from scraping against the sides of the cabinet opening or hitting other components in the drive. Place the board on a flattened static bag on a clean and sturdy surface. For example, on a workbench or a desk.

When the repair is complete and you are ready to reinstall the drive, first slide the board into the cabinet. The board is 13 inches by 5.75 inches with holes in the four corners. Align the board with the space in the metal rack designed to secure the board and use the four screws to secure it. The screws should be snug but not overtightened. Too much pressure can cause the board to crack or chip.
