DS200KLDBG1ABC General Electric Display Board

The DS200KLDBG1ABC is a GE component used within the Mark V Speedtronic system.  The Mark V was one of the last of the Speedtronic systems for the control of gas or steam turbines.  It is a flexible microprocessor-based control system with TMR architecture, designed with built-in diagnostics and online maintenance.  The DS200KLDBG1ABC is no longer sold by GE, but can be found through AX Control as both a reconditioned unit and as liquidated surplus (new-used) stock.  Please note that DS200 series boards are older units without updated firmware or components; if these updates are necessary for your system please review similar boards in the DS215 series.

The DS200KLDBG1ABC functions as a display board.  It is a large, rectangular board with only a few well-spaced components.  This includes thirty-two vertical light components placed in four lines of eight in the bottom right quadrant of the board.  Integrated circuits and resistor network arrays are placed between these lights.  More integrated circuits are clustered in the bottom left corner, including field programmable gate arrays and at least one oscillating chip.   The board has several board connectors, including two vertical pin components.   The board has two jumper switches, capacitors, diodes, and resistors.   The top of the board is populated by seven LED displays.  These displays are designed for numerical display, using sixteen-segment digits.   The board is marked with codes like C-ESS and 6BA01.  The corners and edges of the board are drilled to allow for mounting.
