The 5AP1130.156C-001 is a color touch screen automation device from B&R. It has the following functional features:

Display function: Equipped with 15.6-inch TFT color touch screen and LCD backlight, brightness can be adjusted between 40 to 400cd/m², can adapt to different environmental brightness requirements. With 1920×1080 pixels FHD full HD resolution, can clearly display rich images and text information, 16.7 million color display makes the screen color more rich, realistic, to provide users with a clear and intuitive visual experience.

Touch operation function: PCT project-type capacitive touch technology, sensitive and accurate operation, fast response, support multi-touch, convenient for users to carry out various operations, such as click, slide, zoom, etc., greatly improve the efficiency and convenience of human-computer interaction.

Protection function: The front protection level reaches IP65, which can effectively dust and waterproof, and can work stably in harsh industrial environments such as dusty and humid to ensure the reliability and service life of the equipment. The back protection class is IP20, which plays a certain role in protecting the internal circuit.

Environmental adaptation function: The working temperature range is between 0 and 55 degrees Celsius, the storage and transportation temperature range is between -20 and + 70 degrees Celsius, which can adapt to different working environment temperatures. The allowable vibration during operation is 0.7g, which has good seismic performance and can be operated stably in industrial sites with certain vibration.

Compatibility and expansibility: Equipped with a wealth of interfaces, can easily connect and communicate with other devices, such as PLC, sensors, actuators, etc., to achieve system integration and expansion. Supports a variety of communication protocols, and can interact with different brands and different types of devices, with good compatibility.

Safety and certification function: Through the EMC certification, with good electromagnetic compatibility, can work normally in a complex electromagnetic environment without interference, but also will not cause electromagnetic interference to the surrounding equipment, to ensure the stability and reliability of the entire system

The following is relevant information about 5AP1130.156C-001:

5AP1130.156C-001 is a color touch screen automation PLC/DCS control module device. It is equipped with a 15.6-inch TFT color touch screen and LCD backlight, with a brightness range of 40 to 400 cd/m2, a 1920 x 1080 pixel FHD (Full HD) resolution, and 16.7 million colors. The front protection level of this monitor is IP65, the panel size is 414 millimeters wide, 258.5 millimeters high, weighs 3.7 kilograms, the operating temperature range is 0 to 55 degrees Celsius, the storage and movement temperature range is -20 to+70 degrees Celsius, and the back protection level is IP20. The allowed vibration during operation is 0.7 g, and this model has passed EMC certification and is equipped with a 3M controller. It uses PCT (Projection Capacitive Touch) technology with a contrast ratio of 1500:1. This setting applies to all ports of relays that support PTP, for example, PTP DOMAIN NUMBER ranges from 0 to 255, with a default value of 0; The PTP VLAN priority range is 0 to 7, with a default value of 4; The PTP VLAN ID range is 0 to 4095, with a default value of 0.

Controller for 5AP1130.156C-001

5AP1130.156C-001 Color Touch Screen Automation PLC/DCS Control Module Equipment, as an integrated device of color touch screen and control module, plays an important role in industrial automation control. The device may have adopted advanced PLC (Programmable Logic Controller) or DCS (Distributed Control System) technology to achieve precise control of industrial production processes. In practical applications, users can perform intuitive operations and monitoring through the touch screen. At the same time, the controller can process various input signals according to preset programs and algorithms, and output control signals to drive the actuator, achieving automated control of the production process. For example, in the production line of a large factory, 5AP1130.156C-001 can monitor the real-time operation status of equipment, adjust the operating parameters of equipment according to production needs, and improve production efficiency and product quality.

5AP1130.156C-001 is an industrial equipment with excellent performance. It has a high-resolution color touch screen, which is sensitive and convenient to operate; High protection level, able to adapt to various harsh industrial environments; Although the specific certification situation is currently unclear, it can be inferred that it has undergone strict quality testing and certification. The controller of this device adopts advanced automation control technology, which can achieve precise control of industrial production processes. In the field of industrial automation, 5AP1130.156C-001 has broad application prospects and can provide strong support for enterprises to improve production efficiency, reduce costs, and enhance product quality.
