AZM 170-02ZRK Safety lock switch has the following product functions:

Electrical performance

Rated control voltage: 24V AC/DC, suitable for various electrical systems.

Switching element: Two normally closed (NC) contacts with double-break switching contacts provide reliable circuit control.

Current and voltage capacity: at 230V AC, the current can reach 4A; When the DC is 24V, the current is 2.5A, which can meet the requirements of different loads.

Power consumption: Maximum power consumption 12W, more energy saving.

Mechanical characteristic

Shell material: Made of glass fiber reinforced thermoplastic, with self-extinguishing characteristics, durable, IP67 protection class, can adapt to harsh environments.

Size: Length 30mm, width 90mm, height 84mm, compact design, easy to install in space limited equipment.

Installation method: Install by 2 M5 screws, secure and convenient installation.

Mechanical life: At least 1 million operations, with a long service life.

Retainer: The retainer is 1000N according to EN ISO 14119, and the maximum retainer is 1300N, ensuring that the safety door or guard remains locked while closed.

Latch force: 30N to ensure that the protective door can remain closed after unlocking.

Safety function

Safety classification: In accordance with EN ISO 13849-1, the performance level can reach Class C (when used in a single channel) or Class D (when used in a dual channel and paired with the right logic unit), providing reliable security protection.

Troubleshooting: Used when troubleshooting of single-channel mechanisms is allowed and adequate protection against misoperation is guaranteed.

Manual release: Equipped with manual release function, the M5 triangle key can be manually released from the bottom to facilitate the opening of the safety door in case of emergency or maintenance.

Anti-false lock protection: It has an interlock function to prevent false lock and ensure that the security door is correctly closed and locked.

Environmental adaptability

Operating temperature: The ambient temperature range is -25 ℃ to + 60℃, and the storage and transportation temperature range is -25 ℃ to + 85℃, which can adapt to different working ambient temperature changes.

Altitude: It is allowed to be installed at an altitude of no more than 2000 meters
