Product Description

The General Electric DS200DCFBG1A is a power supply board manufactured for the Mark V board series. Power supplies for both control levels and the enclosure fan is provided by this board. DC2000, CB2000, FC2000, ME2000, and AC2000 series drives can all use this supply card. EX2000 series also uses this board, but interacts differently than the drives do. Sourced input power from the control power transformer to the board can range from 38 to 115 VAC. A frequency range of 0 to 500 kHz accompanies outputs by the board, depending on inputted voltages.

DS200DCFBG1A features a number of circuitries that interface with the installed drive. A control level supply, a motor field power, driver, and AC/DC monitoring circuitries are included on the board. Twelve jumpers and seven DIP switches are integrated into the board, providing the user with configurable system options. Onboard status indicators, two LED and one neon, give users diagnostic information regarding fuse statuses. Users are given five test points to check voltage levels throughout the board. Three protective fuses found on the unit protect the power supply from any interruptions.

Preserving the board and its installed drive is dependent upon users following all GE provided installation and storage parameters. Both the device manual and datasheet contain a complete walkthrough to wiring DS200DCFBG1A. The manufacturer, General Electric, was the original technical support provider for this board.

AX Control’s trusted sales team is happy to help with all of your automation needs. Pricing and availabilities on all parts and repairs is available by contacting our staff by phone or email.
